Features
. Dim-to-Warm from 2000K-3000K
. High effficcy up to 100lm/W
. Air-tight, BBC RT2020 for fix version\
. Directly Insulation coverable(4.5W), ISORED(4.5W)
. Super low profile of 48mm in height
. Silicone gasket ensures IP44 Front/IP20 back
. Phase-cut/Triac Dimmable
. 2 x 2.5mm2 push-fit connector with looping function
. Die-casting aluminum body and bezel
Datasheet
Product Code | 4.DL.172.N11 | 4.DL.173.N11 |
Product Name | Vila G2 68F 580DTW | Vila G2 68A 580DTW |
Input voltage | 220-240V | 220-240V |
Adjustable | Fixed | Adjustable(±25°) |
Power | 6W | 6W |
Lumen Output | 580lm | 580lm |
Beam Angle | 38°, 60° | 38°, 60° |
Power factor | 0.9 | 0.9 |
Dimmable | Phase-cut/Triac | Phase-cut/Triac |
CCT Option | 2000K-3000K Dim-to-Warm | 2000K-3000K Dim-to-Warm |
CRI Option | CRI82(CRI90 on request) | CRI82(CRI90 on request) |
Dimension(mm) | D90*H45 | D90*H45 |
Cut-out(mm) | 68-82 | 68-82 |
Suitable for Ceiling Thickness(mm) | 1-20 | 1-20 |
Direct Insulation Coverable | NO | NO |
Air-tight | Yes | NO |
Electrical Connection | Incl. connection box, 2x2.5mm2 push-fit looping terminals | Incl. connection box, 2x2.5mm2 push-fit looping terminals |
IP Class | IP44 front, IP20 back | IP44 front of engine, IP20 others |
Finish | Black, White, Brush Nickel | Black, White, Brush Nickel |
Carton Size(mm) | 365x220x325 | 365x220x325 |
Qty. /Carton | 30pcs | 30pcs |
PCS/Container | 20' GP: 33,600pcs 40' GP: 67200pcs | 20' GP: 33,600pcs 40' GP: 67200pcs |
Lifespan(hrs) | 35,000 | 35,000 |
Warranty(years) | 3 | 3 |
